31009 - FLAMCO Flamcovent Smart Air Separator 250 F (10.0 bar)

Air & Dirt Separators - Air Separators - Air Separators DN50 - 600 » FLAMCO - Flamcovent Smart Flanged Air Separator

Optimum deaeration combined with energy retention.

The new Flamcovent Smart air separators remove even the tiniest micro-bubbles from the installation water.

The Flamco Smart performs 60% better than conventional air separators, while the flow resistance has been reduced to a negligible level.
  • With flanged connection according to EN 1092-1 PN16.
  • Maximum working pressure: 10 bar.
  • Suitable for systems with a maximum flow temperature of 120 °C.
  • Suitable for glycol solutions of up to 50%.
  • In accordance with Pressure Equipment Directive 2014/68/EU.

Documents

CAD
Flamco - Flamcovent Smart F - DWG CAD 10 Sep 2018
Installation
Flamco - Flamcovent Smart - Installation Instructions 05 Sep 2018
Marketing
Flamco - Flamcovent Clean Smart F (Sizes DN 50-600) - Brochure 05 Sep 2018
Flamco - Product Overview 29 Aug 2018
KE KELIT Climate Control - Heating Systems Product Catalogue 26 Jun 2019
Packaging Data - Flamco, Simplex Meibes 14 Apr 2023
Specifications
Flamco - Flamcovent Smart F - Specification Text 10 Sep 2018
Technical
Flamco - Flamcovent Smart F - Data Sheet 05 Sep 2018
Flamco - Venting Range & Air/Dirt Separators - Catalogue 04 Sep 2018
Login or register to create projects and view pricing.

Product Data


Air & Dirt Separator Data
Code Description Capacity Connection (DN) Connection (mm) Kv (m3/h) Weight
31004 FLAMCO Flamcovent Smart Air Separator 80 F (10.0 bar) 25 80 DN 88.9 209 25
31001 FLAMCO Flamcovent Smart Air Separator 50 F (10.0 bar) 8 50 DN 60.3 93 14
31002 FLAMCO Flamcovent Smart Air Separator 65 F (10.0 bar) 8 65 DN 76.1 140 16
31003 FLAMCO Flamcovent Smart Air Separator 65 F (10.0 bar), 4 Hole 8 65 DN 76.1 140 16
31005 FLAMCO Flamcovent Smart Air Separator 100 F (10.0 bar) 25 100 DN 114.3 311 29
31006 FLAMCO Flamcovent Smart Air Separator 125 F (10.0 bar) 59 125 DN 139.7 459 48
31007 FLAMCO Flamcovent Smart Air Separator 150 F (10.0 bar) 60 150 DN 168.3 675 52
31008 FLAMCO Flamcovent Smart Air Separator 200 F (10.0 bar) 123 200 DN 219.1 1340 80
31009 FLAMCO Flamcovent Smart Air Separator 250 F (10.0 bar) 287 250 DN 273.0 1952 158
31010 FLAMCO Flamcovent Smart Air Separator 300 F (10.0 bar) 333 300 DN 323.9 2830 184
31011 FLAMCO Flamcovent Smart Air Separator 350 F (10.0 bar) 646 350 DN 355.6 4084 321
31012 FLAMCO Flamcovent Smart Air Separator 400 F (10.0 bar) 731 400 DN 406.4 5866 348
31013 FLAMCO Flamcovent Smart Air Separator 500 F (10.0 bar) 1384 500 DN 508.0 8387 635
31014 FLAMCO Flamcovent Smart Air Separator 600 F (10.0 bar) 2390 600 DN 610.0 11939 963
