27021 - FLAMCO Prescor Safety Valve 3/4 x 3/4 - 1.8bar
Valves - Safety Valves - Safety Valves »
FLAMCO - Prescor Safety Valve
Safety valve designed for closed central heating systems.
Prescor safety valves have a special shape which, not only achieves a perfect seal but also a large blow off capacity.
Valve seal made of high-quality rubber which is heat resistant to 140 °C and where the hardness of the rubber adjusts to the set pressure of the safety valve (i.e. the valve cannot stick to the seat).
All valves are tested prior to dispatch.
Specially designed pop action for full discharge at opening pressure.
Minimum/Maximum working temperature: -10 °C / 120 °C.
Peak load: 140 °C.
Product Data
| 27023 |
FLAMCO Prescor Safety Valve 3/4 x 3/4 - 1.5bar |
1.5 bar
|
3/4" x 3/4"
|
Female/Female
|
115 kW
|
| 27020 |
FLAMCO Prescor Safety Valve 3/4 x 1 - 2.5bar (TRD) |
2.5 bar
|
3/4" x 1"
|
Female/Female
|
100 kW
|
| 27021 |
FLAMCO Prescor Safety Valve 3/4 x 3/4 - 1.8bar |
1.8 bar
|
3/4" x 3/4"
|
Female/Female
|
125 kW
|
| 27024 |
FLAMCO Prescor Safety Valve 3/4 x 1 - 3.0bar (TRD) |
3 bar
|
3/4" x 1"
|
Female/Female
|
100 kW
|
| 27025 |
FLAMCO Prescor Safety Valve 3/4 x 3/4 - 3.0bar |
3 bar
|
3/4" x 3/4"
|
Female/Female
|
165 kW
|
| 27026 |
FLAMCO Prescor Safety Valve 3/4 x 3/4 - 2.5bar |
2.5 bar
|
3/4" x 3/4"
|
Female/Female
|
85 kW
|
| 27028 |
FLAMCO Prescor Safety Valve 3/4 x 3/4 - 4.0bar |
4 bar
|
3/4" x 3/4"
|
Female/Female
|
200 kW
|
| 27034 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 2.5bar |
2.5 bar
|
1" x 1 1/4"
|
Female/Female
|
355 kW
|
| 27037 |
FLAMCO Prescor Safety Valve 1 1/4" x 1 1/2" - 4.0bar |
4 bar
|
1 1/4" x 1 1/2"
|
Female/Female
|
710 kW
|
| 27039 |
FLAMCO Prescor Safety Valve 1 1/4" x 1 1/2" - 5.0bar |
5 bar
|
1 1/4" x 1 1/2"
|
Female/Female
|
845 kW
|
| 27040 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 4.0bar |
4 bar
|
1" x 1 1/4"
|
Female/Female
|
485 kW
|
| 27042 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 1.5bar |
1.5 bar
|
1" x 1 1/4"
|
Female/Female
|
275 kW
|
| 27043 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 2.0bar |
2 bar
|
1" x 1 1/4"
|
Female/Female
|
320 kW
|
| 27044 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 2.5bar (TRD) |
2.5 bar
|
1" x 1 1/4"
|
Female/Female
|
200 kW
|
| 27045 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 3.0bar |
3 bar
|
1" x 1 1/4"
|
Female/Female
|
395 kW
|
| 27047 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 3.5bar |
3.5 bar
|
1" x 1 1/4"
|
Female/Female
|
445 kW
|
| 27049 |
FLAMCO Prescor Safety Valve 1 x 1 1/4 - 5.0bar |
5 bar
|
1" x 1 1/4"
|
Female/Female
|
580 kW
|
| 27055 |
FLAMCO Prescor Safety Valve 1 1/4" x 1 1/2" - 2.5bar (TRD) |
2.5 bar
|
1 1/4" x 1 1/2"
|
Female/Female
|
350 kW
|
| 27056 |
FLAMCO Prescor Safety Valve 1 1/4" x 1 1/2" - 3.0bar |
3 bar
|
1 1/4" x 1 1/2"
|
Female/Female
|
580 kW
|
| 27602 |
FLAMCO Prescor Safety Valve 1/2 x 1/2 - 1.8 bar |
1.8 bar
|
1/2" x 1/2"
|
Female/Female
|
95 kW
|
| 27606 |
FLAMCO Prescor Safety Valve 1/2 x 1/2 - 4.0 bar |
4 bar
|
1/2" x 1/2"
|
Female/Female
|
155 kW
|
| 27608 |
FLAMCO Prescor Safety Valve 1/2 x 1/2 - 1.5 bar |
1.5 bar
|
1/2" x 1/2"
|
Female/Female
|
85 kW
|
| 27630 |
FLAMCO Prescor Safety Valve 1/2 x 3/4 - 2.5 bar (TRD) |
2.5 bar
|
1/2" x 3/4"
|
Female/Female
|
50 kW
|
| 27634 |
FLAMCO Prescor Safety Valve 1/2 x 3/4 - 3.0 bar (TRD) |
3 bar
|
1/2" x 3/4"
|
Female/Female
|
50 kW
|
| 27665 |
FLAMCO Prescor Safety Valve 1/2 x 1/2 - 3.0 bar |
3 bar
|
1/2" x 1/2"
|
Female/Female
|
125 kW
|
| 27675 |
FLAMCO Prescor Safety Valve 1/2M x 1/2 - 3.0 bar |
3 bar
|
1/2" x 1/2"
|
Male/Female
|
125 kW
|
