13358 - FLAMCO Flexon P Expansion Vessel 80L, 1.5 (3bar)

Expansion Systems - Expansion Vessels - Small (<110L) » FLAMCO - Flexcon P Expansion Vessel 18 - 50L

Oval shaped expansion vessels with reduced height and suspension eye.

For use in sealed heating installations (acc. to EN12828) and chilled water (cooling) installations.

Space-saving alternative for small installations.

Diaphragm: butyl rubber.

Maximum working pressure: 3.0 bar.
Suitable for systems with a maximum flow temperature of 120°C.
Maximum temperature diaphragm: 90°C.

The Flamco Flexcon Calculation tool enables you to size and configure your pressurisation unit and all accessories you need for safe and problem free pressurisation of heating systems, cooling systems, water heating installations or pressure boosting sets.

View the tool here: https://source-to-emitter.com/

Documents

Installation
Flamco - Flexcon - Installation Instructions	06 Sep 2018
Marketing
Flamco - Product Overview	29 Aug 2018
KE KELIT Climate Control - Heating Systems Product Catalogue	26 Jun 2019
Packaging Data - Flamco, Simplex Meibes	14 Apr 2023
Technical
Flamco - Expansion Vessel Selection Table	31 Aug 2018
Flamco - Expansion Vessels & Pressurisation Equipment - Catalogue	04 Sep 2018
Flamco - Flexcon P 18-50L - Data Sheet	06 Sep 2018

Product Data

		Expansion Vessel Data
Code	Description	Capacity	Pre-charge (bar)	System Connection	Weight (kg)
13357	FLAMCO Flexcon P Expansion Vessel 50L, 1.5 (3bar)	50 litres	1.5	G 3/4" M	11.8
13316	FLAMCO Flexcon P Expansion Vessel 18L, 1.0 (3bar)	18 litres	1.0	G 3/4" M	5.7
13326	FLAMCO Flexcon P Expansion Vessel 25L, 1.0 (3bar)	25 litres	1.0	G 3/4" M	7.7
13336	FLAMCO Flexcon P Expansion Vessel 35L, 1.0 (3bar)	35 litres	1.0	G 3/4" M	8.9
13358	FLAMCO Flexon P Expansion Vessel 80L, 1.5 (3bar)	18 litres	1.0	G 3/4" M	5.7
